Product Details

Weight

23 kg / 51 lbs

Power supply

100 to 240 V (± 10%), 50 to 60 Hz

Dimensions

48 cm x 40 cm x 48 cm / 16 x 19 x 19 in

Printer

Compatible models with Linux drivers

Throughput

Approximately 50 tests / hour

Screen

Colour LCD touch screen of 12.1 in

Data management

Linux™

Transmit patient & QC to LIS

Uni-directional or bi-directional connection

Communication Protocol: ASTM

Connection: RS232, Ethernet, USB

Memory

10,000 results + Graphics

Quality Control Management

3 controls levels (low, normal, high)

Target values download (USB)

Levey-Jennings Graphs

Radar Graphs

XB on 3 or 9 parameters, mean of 20 runs

Compatible with QCP

Logs

Reagents, calibration, Quality Control, blank cycle, users, settings, service, communication

Parameters (27)

WBC, NEU# & NEU%, LYM# & LYM%, MON# & MON%, EOS# & EOS%, BAS# & BAS%, LIC# & LIC%*, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-CV, RDW-SD*, PLT, MPV, PCT*, PDW*, P-LCC*, P-LCR*

Graphics

High-definition Diff matrix
PLT, RBC curves

Sample-Volume

CBC mode: 20 µL
DIFF mode: 20 µL

Stability

48 hours post-draw stability for CBC parameters, 24 hours post-draw stability for DIFF parameters

Operating sample mode

Open or Closed Tube

Identification

Alphanumeric. Bar-code reader (optional)

WBC

< 3.0%

0-300 x 109/L

RBC

< 2.0%

0-8 x 1012/L

HGB

< 1.5%

0-240 g/L

HCT

< 2.0%

0-67 L/L

PLT

< 5.0%

0-2500 x 109/L

PLT (PLT concentrate)

< 5.0%

0-4000 x 109/L
